Unichem Steel & Alloy Pvt. Ltd. is an expert Manufacturer, Supplier, and Exporter for all standards of Backing Ring Flanges. A Backing Ring Flange is designed to attach sections of pipe or tube or to affix the pipe or tube to an assembly like a pressure vessel, valve, or pump. Backing Ring Flange is joined by bolting, and sealing is completed with the utilization of gaskets and other sealing methods and fixed to the piping system by welding or threading. to achieve optimum client satisfaction, we ensure safe packaging and prompt delivery of the ordered consignment. Our offered SS Backing Ring flange is being developed and designed in accordance by means of the international quality of standards at our infrastructure facility to achieve the highest scales of quality. Keeping in mind the ever-evolving requirements of our respected clients, we are involved in supplying a broad range of Backing Ring Flange in India. Our Backing Ring Flange is manufactured consistent with ANSI, AWWA, JIS, DIN, EN1092-1, BS4504, GOST, SANS1123 standard, etc, and that we also can manufacture Backing Ring Flange consistent with customers drawings. Welcome global advertisers to contact us, we’ll provide professional product solutions.
